SB81 Hydraulic Concrete Rock Breaker Hammer Q345B For 20 Tons Excavator
  • SB81 Hydraulic Concrete Rock Breaker Hammer Q345B For 20 Tons Excavator
  • SB81 Hydraulic Concrete Rock Breaker Hammer Q345B For 20 Tons Excavator
  • SB81 Hydraulic Concrete Rock Breaker Hammer Q345B For 20 Tons Excavator
  • SB81 Hydraulic Concrete Rock Breaker Hammer Q345B For 20 Tons Excavator
  • SB81 Hydraulic Concrete Rock Breaker Hammer Q345B For 20 Tons Excavator
Place of Origin China
Brand Name Hanyun
Certification CE/ISO9001
Model Number HY165
Minimum Order Quantity 1 set/Negotiable
Price Negotiable
Packaging Details Exported plywood box
Delivery Time 3-15 working days
Payment Terms L/C, T/T
Supply Ability 5000 sets per year
Product Details
Type Side Type/top Type/ Box Silence Type Hydraulic Breaker Hammer Application Minin, Demilation, Bridge, Construction, Road
Material Q345B, 42CrMo, 20CrNiMo3, 20CrMo Suitable Excavator 1-80tons
Condition New Packing Export Pallet
Chiesel Diameter 45mm/68mm/75mm/85mm/100mm/135mm/140mm OEM Avaliable
Color Customized Color Warranty 1 Year
High Light

Hydraulic Concrete Rock Breaker Hammer

,

SB81 Hydraulic Breaker Hammer

,

Q345B Hydraulic Breaker Hammer
Product Description

Hot sale direct manufacturer SB81 hydraulic hammer concrete rock breaker for 20 tons excavator

HANYUN Hydraulic Hammer

1. Selected raw material - high quality heavy duty wear resistant steel.

2. Leading heat treatment technology. Heat resistance and abrasion resistance are enhanced.

3. The device can adjust the flow from excavator and power source, so it can adjust the impact force and beat frequency according

to different working situation.

4. High-quality and durable wear parts ,longer use, easy maintenance.

5. Strong " hydraulic + nitrogen " impact system, increase stability.

6. Advanced manufacturing facilities and technology, introduced from South Korea.

7. High energy and impact frequency, High-performance optimized hydraulic unit.

SB81 Hydraulic Concrete Rock Breaker Hammer Q345B For 20 Tons Excavator 0

SB81 Hydraulic Concrete Rock Breaker Hammer Q345B For 20 Tons Excavator 1



Three types of hydraulic breaker hammers

SB81 Hydraulic Concrete Rock Breaker Hammer Q345B For 20 Tons Excavator 2



Parameter of HANYUN side type hydraulic breaker



HANYUN Side type Hydraulic breaker
Model Total weight (KG) Diameter of chisel(MM) Weight of chisel(KG) Operating pressure(BAR) Hydraulic flow range(L/MIN) Impact frequency(BPM) Carrier weight (ton) Valve Ass'y Position
HY400 70 40 4 90-120 15-25 800-1400 0.8-2.5 Internal
HY450 95 45 8 90-120 20-30 700-1200 1.2-3.0 Internal
HY530 158 53 9 90-120 25-50 600-1100 2.5-4.5 Internal
HY680 263 68 18 110-140 40-70 500-900 4-7 Internal
HY750 334 75 22 120-150 50-90 400-800 6-9 Internal
HY850 493 85 29 130-160 60-100 400-800 7-14 Internal
HY1000 736 100 57 150-170 80-110 350-700 10-15 Internal
HY1200 1374 120 89 150-170 90-120 350-650 15-18 Internal
HY1350 1653 135 115 160-180 130-150 400-600 18-26 Internal
HY1400 1774 140 135 160-180 120-180 350-5000 18-26 Internal
HY1500 2281 150 164 160-180 150-190 350-700 27-35 Internal
HY1550 2577 155 183 160-180 180-240 300-450 28-35 Internal
HY1600 3075 160 200 160-180 200-260 250-400 30-40 Internal
HY1650A 2751 165 224 160-180 200-260 250-400 30-40 Internal
HY1650B 3277 165 215 170-200 200-260 250-400 30-40 Internal
HY1750 3905 175 247 260-270 250-300 200-300 45-50 Internal
HY1850 4365 185 269 270-280 220-290 150-250 45-50 Internal
HY1950 4841 185 269 270-280 250-320 150-250 50-60 Internal
HY2000 5800 200 321 270-280 250-320 150-250 50-60 Internal







Picture of HANYUN breaker

SB81 Hydraulic Concrete Rock Breaker Hammer Q345B For 20 Tons Excavator 3SB81 Hydraulic Concrete Rock Breaker Hammer Q345B For 20 Tons Excavator 4

SB81 Hydraulic Concrete Rock Breaker Hammer Q345B For 20 Tons Excavator 5



HANYUN FACTORY

SB81 Hydraulic Concrete Rock Breaker Hammer Q345B For 20 Tons Excavator 6SB81 Hydraulic Concrete Rock Breaker Hammer Q345B For 20 Tons Excavator 7SB81 Hydraulic Concrete Rock Breaker Hammer Q345B For 20 Tons Excavator 8SB81 Hydraulic Concrete Rock Breaker Hammer Q345B For 20 Tons Excavator 9SB81 Hydraulic Concrete Rock Breaker Hammer Q345B For 20 Tons Excavator 10



FAQ

Q: Are you a manufacturer?
A: Yes, our factory was established in 2011.
Q: Are you sure your product will fit my excavator?
A: Our machines are suitable for most excavators.Show us your excavator model, we'll confirm the solution.
Q: How about your products warranty?
A: 12 months warranty for hydraulic breaker6 months warranty for spare parts beyond the warranty period.
Q: Can you produce according to customers design?
A: Sure, OEM/ODM service available.We are professional manufacturer in Jiangsu.
Q: What's the MOQ and payment terms?
A: MOQ of hydraulic breaker is 1set.Payment via T/T, Western Union accepted, other terms can be negotiated.
Q: How about delivery time?
A: 5-25 work days after the payment
Q: Which country have you exported?
A:Saudi Arabia, Korea,Thailand, Indonesia, India, Canada,Switzerland ,Vietnam , Iran, Turkey, Peru, Egypt, Brazil, Mexico, South Africa etc.
Q: How about the package?
A: Our machines wrapped by stretch film packed by pallet or poly wood case or as requested.
