42CRMO 40CRMO Hydraulic Breaker Hammers Yellow Rock Drill Breaker Excavator

42CRMO 40CRMO Hydraulic Breaker Hammers Yellow Rock Drill Breaker Excavator

  • High Light

    42CRMO Hydraulic Breaker Hammers

    ,

    40CRMO Hydraulic Breaker Hammers

    ,

    Yellow rock drill breaker excavator

  • Name
    Excavator Rock Concrete Breaker
  • Shell Materials
    High Strength Manganese Steel
  • Chisels Materials
    40CRMO & 42CRMO
  • Color
    Yellow, Red, Blue And Other Colors
  • Size
    Customized
  • Working Purpose
    Concrete Breaking
  • Excavator Used
    KOMATSU, KOBELCO, HYUNDAI, CAT, SANY
  • Striking Force
    Large Striking Force
  • Place of Origin
    China
  • Brand Name
    HANYUN
  • Model Number
    HY180
  • Minimum Order Quantity
    1 set
  • Price
    Negitionable
  • Packaging Details
    Fumigation-free plywood box
  • Delivery Time
    3-15 working days
  • Payment Terms
    L/C, T/T
  • Supply Ability
    1000 sets per year

42CRMO 40CRMO Hydraulic Breaker Hammers Yellow Rock Drill Breaker Excavator

Complete Models Excavator Rock Concrete Breaker With Breaker Chisels



(1) How to select one suitable excavator rock concrete breaker?

Excavator rock concrete breaker is mainly used for breaking rocks. As selecting one suitable excavator rock

concrete breaker, we shall consider:

1. The working pressure and working flow options need to match the hydraulic performance of the excavator,

2.  The drill rod diameter and strike frequency can be selected according to the working conditions.



For example, to crush hard rocks, you can choose a breaker with a larger drill rod diameter

and a higher hit frequency, which will have a greater impact force, and then use a special drill rod according to

different working conditions.



(2) Main Technical Parameters on Excavator Rock Concrete Breaker

Model HY180
Total weight (KG) 4950
Size (L*W*H) (MM) 2240*750*1620
Driving oil pressure (KG) 280-300
Driving oil volume (MIN) 220-270
Striking frequency(BPM) 180-200
Rubber hose diameter (INCH) 1.2
Drill rod diameter(MM) 180
Drill rod weight(KG) 300
Applicable vehicle weight (T) 42-48

42CRMO 40CRMO Hydraulic Breaker Hammers Yellow Rock Drill Breaker Excavator 0



(3) Main Products from Hanyun

Hanyun is one leading manufacturer of hydraulic hammers for different excavators with various models.

It was founded in Zhengzhou city, China in 2012. For about 10 years,

it has kept being dedicated in the field of design, develop and fabricate different hydraulic breaker hammers

and related spare parts.

Main products of Hanyun as below:

1. Excavator Rock Concrete Breaker;

2. Breaker chisels ;

3. Excavator compactors;

4. Hydraulic pulverizer;

5. Excavator quick hitches;

6. Excavator breaker attachment.



(4) Warehouse Show on Excavator Rock Concrete Breaker

42CRMO 40CRMO Hydraulic Breaker Hammers Yellow Rock Drill Breaker Excavator 1



(5) Hanyun Family

Foundation Date 2012
Factory Address Zhengzhou city, Henan, China
Company Type Manufacturer + Joint-stock enterprise
Annual sales About USD 30 million
Family members 210
